| ProductsName: |
Windscreen wiper |
| Products Model: |
|
| view: |
1470 |
| by: |
junling |
| date: |
2009-11-04 17:32:48 |
|
|
  |
|
|
| ProductsIntroduce |
|
No |
Number of part |
Quantity |
Applicability |
Designation |
|
- |
WG1630740002 |
1 |
|
Wind screen wipper assembly |
|
- |
WG03740002 |
1 |
|
Wind screen wipper assembly
|
|
1 |
116100740003 |
1 |
|
Electric machine of
Wind screen wipper
|
|
- |
AZ1630740038 |
1 |
|
Lever assembly |
|
- |
116100740037 |
1 |
|
left Lever assembly
|
|
2 |
116100740011 |
3 |
|
Wind screen wipper arm assembly
|
|
3 |
116100740012 |
3 |
|
Doctor blade assembly |
|
4 |
116000740226 |
1 |
|
Nut |
|
5 |
116100740027 |
3 |
|
Hexagon nut |
|
6 |
116000740215 |
3 |
|
Rubber pat |
|
7 |
116100740016 |
3 |
|
Wave washer |
|
8 |
116100740017 |
3 |
|
Hexagon nut
|
|
9 |
116400740219 |
3 |
|
Hexagon nut
|
|
10 |
116000740218 |
3 |
|
Cover assembly |
|
11 |
116000740232 |
3 |
|
Spring washer |
|
12 |
116100740701 |
3 |
|
Doctor blade |
|
17 |
16000740033 |
1 |
|
Tapping clip |
|
18 |
Q150B0616 |
1 |
|
Hexagon screw
|
|
19 |
Q41206 |
1 |
|
Tap-locking washer of outer gear |
|
20 |
Q40206 |
1 |
|
big washer |
|
21 |
Q340B06 |
1 |
|
Hexagon nut I |
|
22 |
116100740035 |
1 |
Drive right |
Electric machine Bracket assembly of Wind screen wipper(right) |
|
22 |
AZ1630740026 |
1 |
|
Electric machine Bracket assembly of Wind screen wipper |
|
23 |
Q150B0612 |
3 |
|
Hexagon screw |
|
24 |
Q41706 |
3 |
|
Seddle spring washer |
|
25 |
190003869951 |
7 |
Drive right
|
Bolt |
|
26 |
Q40006 |
7 |
|
Small washer |
|
25 |
90003869931 |
7 |
|
Bolt
|
|
29 |
Q40506 |
7 |
|
Heavy spring washer |
|
27 |
16000740020 |
1 |
|
Middle bracke assembly of Wind screen wipper |
|
28 |
116103740046 |
1 |
Drive right
|
Right bracke assembly of Wind screen wipper |
|
28 |
116000740023 |
1 |
|
Left bracke assembly of Wind screen wipper |
|
- |
AZ16307400038 |
1 |
|
Lever assembly |
|
30 |
AZ1630740004 |
1 |
|
Curve lever assembly |
|
31 |
AZ1630740007 |
1 |
|
Turning arm assembly |
|
32 |
116100740006 |
1 |
|
Right lever |
|
33 |
116100740008 |
1 |
|
Wind screen wipper assembly
(45o) |
|
34 |
116100740009 |
1 |
|
Wind screen wipper assembly
(middle) |
|
35 |
116100740044 |
5 |
|
Guard sleeve |
|
36 |
116100740005 |
1 |
|
Left lever |
|
37 |
116100740010 |
1 |
|
Wind screen wipper assembly
(50o) |
|
38 |
116100740045 |
1 |
|
Guard sleeve
|
|
- |
116103740039 |
|
Drive right
|
Right lever assembly
|
|
- |
116100740037 |
|
Drive right
|
Left lever assembly
|
|
39 |
116100740005 |
|
Drive right
|
Left lever assembly
|
|
40 |
116100740010 |
|
Drive right
|
Wind screen wipper assembly
|
|
41 |
116100740045 |
|
Drive right
|
Guard sleeve
| |
|
|
